Early V8 Quick Change Rear
As-Cast With Big Ford Bearing & 31 Spline Axles
As-Cast With Big Ford Bearing & 31 Spline Axles
Measures 56" from hub to hub and have both 5 on 4 1/2" and 5 on 4 3/4" bolt patterns
Designed to accept the new style big Ford brakes with a 2 1/2" offset and the standard Spicer 1310 Chevy 3-1/4" u-joint
3.78 ring and pinion is mounted on a wedgelock differential and accepts common 6 spline quick change gears
Features a semi-floating axel type and a limited slip differential
V8 Winters early quick change rear uses stock appearing ford flanged 31 spline axles, will take after market disc or stock ford brakes. 4.12 ring and pinion, heat treated lower shaft, track differential, axle seals and choice of 10 spline straight cut gears.
Steel tube & bells (big ford) rib rear cover standard.
Use winters semi synthetic hypoid lube with moly 80-90-140 p# winsr1730
Use Moroso mo85850 u joint girdle & stu1643 uni joint
| Categories | Transmission & Drivetrain |
|---|---|
| Manufacturer Part Number | WINSR2550STB |
| Brand | Winters |
| Part Type | Differentials - Quick Changes |
| Cylinders | V8 |
| Vehicle Make | Chevrolet, Ford |
